Energy saving High-Power Luxury Sublimation Roll Heat Press Machine 1700A

FOB Reference Price:Get Latest Price
$11,904.00 - $17,460.00 / Sets | 1 Set/Sets (Min. Order)
Gross Power:
30-45KW
Report Suspicious Activity
Overview
Quick Details
After-sales Service Provided:
Online support, Video technical support
Plate Type:
roll heat press transfer machine
Color & Page:
Multicolor
Certification:
CE Certificate
Usage:
roll heat press transfer machine
Type:
Heat Press Machine
Applicable Industries:
Garment Shops
Condition:
New
Place of Origin:
Guangdong, China
Brand Name:
DBX -roll heat press transfer machine
Model Number:
DBX-roll heat press transfer machine
Automatic Grade:
Automatic
Voltage:
380V/220V
Dimensions(L*W*H):
2800*1300*1600mm
Weight:
1500-35000kg
Warranty:
1 Year
Machine name:
Rotary heat transfer Machine
Heating type:
Oil heating
Diameter of metter:
500mm,600mm,800mm
Heating:
Oil heating
Heating power:
15-28KW
Printing Speed:
150~200m/h
Control panel sceen size:
27cm*35cm
Work table size approx:
175cm*270cm
Effective print width approx:
160cm*270cm
Blanket width approx:
178cm
Supply Ability
Supply Ability:
10 Set/Sets per Month
Packaging & Delivery
Packaging Details
Hard carton and wood for Rotary heat press transfer printing dye sublimation machine
Port
guangzhou

Energy saving High-Power Luxury Sublimation Roll Heat Press Machine 1700A

Product Description

Rotary Heat Press 100% Full Oil Drum Elephant-B model is now available.

There is external tank connected to the oil drum to fill the oil drum full. Full oil drum improves the stability of oil drum temperature. It makes sure that density of color is the same throughout the large format fabric. New Rotary Heat Press 100% full oil drum is excellent for roll-to-roll transfer. Moreover, heating power (working) is 20% lower now. It helps sign producers reduce the electrical cost.

- Aligning Blanket Automatically
- Detecting Temperature on the Surface
- Filling Oil Drum to 100% Full (Saving 30% Power)
- Controlling Temperature Precisely (Controllable Silicon Solid State Relay)
- Minimizing Maintenance Effort (Slip Ring)
- At Least 70% Blanket Coverage
- Blanket Tension Controlled by Piston
- Fabric/Transfer Paper/Tissue Paper Tension Controlled by Compressed Air


Why Choose elephant roll heat press machine?

  • ·Long service life, save your cost.
  • ·One year warranty
  • ·Best digital technology support - avoid problems during production.
  • ·High speed at 250-300 Meters/hour -  Improve production efficiency.



 Features of Elephant New Model Roll Heat Press Machine:

1.Prevent workers hand into the cylinder (when they are working)
2.Having automatic device for deviation and correction of blanket and conveyor belt
3.Having the function to avoid the scissor damaging the blanket
4.The Blanket can be off the heat drum competely for 8cm distance. No need to cool down the
blanket when you want to stop the machine which saves energy, it can also prevent the blanket
burn out when power off suddenly.
5.Machine has explosion-proof equipment and emergency stop button,more safe.
6.having the outer oil tank which is more easy to fill in the oil and more safe
7. With breathable conveyor belt which make fabric heat dissipating faster and prevent color ghosting
8.With updated air expanding equipment for sublimation paper, finished paper and tissue paper.
